Ralston Instruments Field Gauge LC30

Ralston Instruments Field Gauge LC30

$657.91 – $756.00

An affordable panel mounted pressure gauge with high-end features, the new Ralston Instruments Field Gauge LC30 line of digital pressure gauges was designed with the user in mind. They are compact, tough, and reliable with customization options to help you simplify your work and get the job done quickly and accurately.

Accuracy: ±0.1% full scale accuracy

SKU: LC30 Categories: , Tag:

Description

The Ralston Instruments Field Gauge LC30 is the obvious choice for panel mounted applications.

An affordable panel mounted pressure gauge with high-end features, the new Ralston Instruments Field Gauge LC30 line of digital pressure gauges was designed with the user in mind. They are compact, tough, and reliable with customization options to help you simplify your work and get the job done quickly and accurately.

Features

  • Added customization – Easily switch from among 15 standard engineering units with the option to add your own and remove unneeded units.
  • Mounting flange – Allows for installation in a control panel without taking up too much room.
  • Back mounted pressure sensors – Make for easy panel mount installation.
  • USB connection – Connect to calibration management software for live viewing of pressure, customization of engineering units, and calibration.
  • AC mains powered with battery backup – Country adapters for North America, Europe, UK, Australia and China.
  • +/-0.1% full scale accuracy – ASME B40.100 Grade 4A/ISO Class 0.1
  • Increased visibility – Large, easy-to-read display with intuitive controls and bright backlight.
  • Exceptional durability – Withstands abuse and cracking and is waterproof to 1 meter (IP67)
  • Quick, reliable Zero function –  Using a single button
  • Convenient High / Low function – View highest and lowest pressure reached.
  • Menu system – Allows access to additional controls
  • Made in the USA – In Novelty, Ohio

Specifications

Max Pressure 5 PSI / 34 mbar / 30 kPa
15 PSI / 1 bar / 100 kPa
30 PSI / 2 bar / 200 kPa
50 PSI / 3.5 bar / 350 kPa
100 PSI / 7 bar / 700 kPa
300 PSI / 20 bar / 2.00 MPa
500 PSI / 35 bar / 3.50 MPa
1000 PSI / 70 bar / 7.00 MPa
3000 PSI / 200 bar / 20 MPa
5000 PSI / 350 bar / 35 MPa
10000 PSI / 700 bar / 70 MPa
Pressure Measurement Uncertainty +/- 0.1% of Full Scale (ASME B40.100 Grade 4A/ISO Class 0.1)
Measurement Type Gauge Pressure
Gauge Pressure, Gauge Vacuum
Gauge Vacuum
Min Operating Temperature -4 °F / -20 °C
Max Operating Temperature 122 °F / 50 °C
Materials ABS / Polycarbonate Blend, Powder Coated Aluminum
Calibration Certificate NIST traceable (included)
Certifications Certified to CSA Standard C22.2 No. 61010-1, Complies with Pressure Equipment Directive 2014/68/EU, Complies with Low Voltage Directive 2014/35/EU, Complies with Electromagnetic Compatibility Directive 2014/30/EU
Wetted Materials 316 Stainless Steel
USB Connection USB (Micro B)
Media Compatibility Inert Gas, Natural Gas, Petroleum Based Oil, Water, Air, Alcohol, Antifreeze, Ethylene Glycol, Hydraulic Oil, Mineral Oil, Skydrol, Windshield washer fluid, Transmission fluid, Light motor oil, Ralston Calibration Oil
Primary Power AC Mains Power
Backup Power AAA Alkaline (IEC-LR03)
Battery Count 2
Battery Life 1000 Hours
LCD Display 2.4 in / 61 mm segmented LCD Display
Wrench Size 7/8 In / 23 mm
Length 1.75 in / 45 mm
Width 3.4 in / 87 mm
Height 4.1 in / 11 cm
Weight 12.6 oz / 355 grams
Country of origin USA

Additional information

Pressure Range

, , , , , , , , , , , ,

Accuracy

Mounting

Process Connection Location
